BW-600-10 Mud Pump

BW-600-10 Mud Pump

BW-600-10 Mud Pump

BW-600/10 three piston mud pump is horizontal triplex single acting reciprocating piston pump, it is well-suited to shallow well construction, special drilling, shallow petroleum drilling and core drilling over 2000meters, we supply mud pumps with four different displacements and pressure to perfectly satisfy specific drilling applications requiring various diameters, depths and techniques



The flushing fluid utilized by this three piston mud pump shall not contain any chemical impurities that are corrosive to metals and rubber parts. When using mud for flushing, the recommended proportion of water and mud is between 1.03~1.12 viscosity of mud between 18 and 25s, silt content lower than 4%, diameter of sand particles not exceed 3mm, and PH value around 7~8, no tiny mud balls, weeds, leaves and other impurities are allowed in the mud



With sophisticated structure and new materials in China and abroad, small volume and light weight, easy assembly and disassembly as well as long service life of high wear parts, this mud pump enjoys superior performance



Type

Horizontal triplex single acting reciprocating piston pump

Stroke (mm)

110

Cylinder diameter (mm)

100

Pump speed (r/min)

232

162

109

76

Displacement (L/min)

600

415

280

195

Pressure (Mpa)

3.5

5

7.5

10

Input torque (Nm)

810

Input speed (r/min)

550

Max. suction height (m)

2.5 (fresh water)

Suction pipe diameter (mm)

89

Discharge pipe diameter

51

Dimension (L*W*H) (mm)

1400*1040*1520

Weight (kgs)

765
