T6 Series Double Tube Core Barrels

T6 Series Double Tube Core Barrels

 T6 Series Double Tube Core Barrels


These are a continuation of the T2 series, but of a sturdier design and available in larger diameters, 76, 86,101,116, 131, 146mm. They are applied in surface mining and geotechnical drilling.

Size

Hole diameter

Core diameter

Head thread

T6-76

76mm

57mm

As per request

T6-86

86mm

67mm

As per request

T6-101

101mm

76mm

As per request

T6-116

116mm

93mm

As per request

T6-131

131mm

108mm

As per request

T6-146

146mm

123mm

As per request



Components

1

Double tube core barrel head

2

Inner tube

3

Extension tube

4

Core lifter

5

Core lifter case

6

Outer tube

7

Thread protector




Note:

1): Core bit & reaming shell are not supplied with core barrel, and shall be purchase separately

2): 1.5m and 3.0m length core barrels are available
